This model of microscope for surgery is primarily used for ophthalmic eye surgery and examination by ophthalmologists. The main feature of this operation microscope is the motorization of the focusing with controls on the foot pad. The equipment is also portable, being mounted on a rolling wheel base.
The viewing head is binocular. There is no option for an assistant or teaching head. The eyepieces cannot be tilted on a rotating angle as they are on a fixed angle. To tilt the head, the physician tilts the complete head assembly. The microscope head has a three step magnification allowing different powers to be viewed. There is no zoom optics.
The lens is made from high quality imported German glass for reduction in lens aberration. All optics are multi-coated and include mildew proof and anti-reflection coatings. A useful option is a beam splitter, ccd camera adapter, and ccd camera for taking the video image to a cctv monitor for medical personnel in the room to see, or for the operation procedure to be videotaped. Some of the photos show this optional c-mount adapter and beam splitter, but it is an optional accessory.
The microscope can be adapted for other applications with the changing of the bottom lens that controls the focal point, and ultimately, the distance from head to specimen. The included bottom objective lens is 200mm focal distance, but there are other optional objective lens consisting of: f175mm, f250mm, f300mm, f350mm and f400mm. Other optional accessories include a 10x eyepiece pair that will change magnifications seen.
There is also an option to convert the operating microscope equipment to a desktop model by changing the holding bracket and column. For ultimate portability, specifically for those doing medical missions abroad, we recommend the portable package consisting of three canvas bags and a buggy. The surgical microscope has an easy method for quick interchange of bulbs in case of bulb failure during surgery. This surgical operating microscope is made in a US FDA (Food and Drug Administration) registered manufacturing facility as well as has CE certification.
|Magnifications of Eyepiece||12.5x / 16mm|
|Magnifications of Main Microscope||5.3x, 8x, 12x|
|Diameter of Field||38mm, 25mm, 17mm|
|Adjustable Dioptor||+/- 6D|
|Adjustable Interpupillary Distance||50mm - 70mm|
|Illumination Source||12V/100W, Halogen Lamp|
|Illumination Type||6 deg. + 0 deg. Coaxial Illumination|
|Coaxial Illumination||≥30,000 Lx|
|Reaching Range of Arm||870 mm|
|Adjustable Vertical Range||700 mm to 1100 mm|
|Fine Focusing Range||30 mm|
|Voltage||AC220V / AC110V|
|Fuse||AC250V T1.25A, AC125V T2.5A|
|Safety Electrical Standard||IEC601-1|
|Whole Packing Volume||0.2 cbm|
|Total weight||41 Kg|
Five OPTIONAL Objectives: f175mm, f250mm, f300mm, f350mm, f400mm
Magnification and Field of View Chart: (using 12.5x eyepiece)
|Total Magnification||6x, 9x, 14x||4.2x, 6.4x, 9.6x||3.5x, 5.4x, 8x||3x, 4.6x, 6.8x||3x, 4x, 6x|
|Diameter of Visual Field(mm)||33, 22, 15||47.5, 31, 21||57, 38, 25||67, 44, 30||76, 50, 34|
