model: MS-113
DENTAL - ENT
SURGICAL OPERATING MICROSCOPE
USA FDA REGISTERED MANUFACTURER
SURGICAL OPERATING MICROSCOPE
USA FDA REGISTERED MANUFACTURER
price: $6,239.98
s/h: Shipping cost to be determined based on destination and shipping method.
USA
(Food and Drug Administration) Registered Manufacturing Facility. FDA Device Class 1
(Food and Drug Administration) Registered Manufacturing Facility. FDA Device Class 1
Specifications:
This model of ENT / dental surgical operating microscope is identical to model MS-111 with the exception of it having an improved illumination system, longer reach, and a taller column size. The improved lighting gives better and brighter imaging for the ENT surgeon. It is a slightly improved and newer model. Most of the specifications of this model are identical to model MS-111 but they are repeated here to show the difference in arm length and vertical adjustment range. For other details, refer to the text on model MS-111.
| Magnifications of Eyepiece | 12.5x / 16mm |
| Objective | 250 mm |
| Working Distance | 240 mm |
| Magnifications of Main Microscope | 4.2x, 6.4x, 9.6x |
| Diameter of Field | 47.5mm, 31mm, 21mm |
| Adjustable Dioptor | +/- 6D |
| Adjustable Interpupillary Distance | 50mm - 70mm |
| Illumination Source | 12V/100W, Halogen Lamp |
| Illumination Type | 6 deg. + 0 deg. Coaxial Illumination |
| Coaxial Illumination | ≥30,000 Lx |
| Reaching Range of Arm | 1030 mm |
| Adjustable Vertical Range | 750 mm to 1150 mm |
| Fine Focusing Range | 30 mm |
| Voltage | AC220V / AC110V |
| Fuse | AC250V T1.25A, AC125V T2.5A |
| Safety Electrical Standard | IEC601-1 |
| Whole Packing Volume | 0.24 cbm |
| Carton Qty | 1 |
| Total weight | 51 Kg |
Optional Accessory:
Five OPTIONAL Objectives: f175mm, f200mm, f300mm, f350mm, f400mm
Magnification and Field of View Chart: (using 12.5x eyepiece)
| Objective | F175mm | F200mm | F300mm | F350mm | F400mm |
| Total Magnification | 6x, 9x, 14x | 5.3x, 8x, 12x | 3.5x, 5.4x, 8x | 3x, 4.6x, 6.8x | 3x, 4x, 6x |
| Diameter of Visual Field(mm) | 33, 22, 15 | 38, 25, 17 | 57, 38, 25 | 67, 44, 30 | 76, 50, 34 |
